Technical specifications
12.2 Electromagnetic compatibility
CPU 1515SP PC2 (F/T/TF)
72 Operating Instructions, 09/2018, A5E42603425-AA
Sinusoidal disturbance
The following table shows the electromagnetic compatibility of the CPU 1515SP PC2 with
regard to sinusoidal disturbances.
● RF radiation
Table 12- 2 Sinusoidal disturbance variables with RF radiation
RF radiation according to IEC 61000-4-3/NAMUR 21
Electromagnetic RF field, amplitude-modulated
corresponds to degree of
severity
80 to 1000 MHz; 1.0 to 2.0 GHz
2.0 GHz to 6.0 GHz
3
10 V/m 3 V/m
80% AM (1 kHz)
● RF coupling
Table 12- 3 Sinusoidal disturbance variables with RF coupling
RF coupling according to IEC 61000-4-6
corresponds to degree of
severity
(10 kHz) 150 kHz to 80 MHz 3
10 V
rms
unmodulated
80% AM (1 kHz)
150 Ω source impedance
Emission of radio interference
Interference emission of electromagnetic fields in accordance with IEC61000-6-4 (measured
at a distance of 10 m).
Table 12- 4 Interference emission of electromagnetic fields
Frequency
Emitted interference
30 MHz to 230 MHz
< 40 dB (µV/m)Q
230 MHz to 1000 MHz
< 47 dB (µV/m)Q
Emission of interference via AC supply voltage in accordance with EN 55016.
Table 12- 5 Interference emission via the AC power supply
Frequency
Emitted interference
0.15 to 0.5 MHz <79 dB (µV) Q
<66 dB (µV) M
0.5 to 30 MHz <73 dB (µV) Q
<60 dB (µV) M
