Wiring
7.3 Electrical configuration
CPU 1515SP PC2 (F/T/TF)
38 Operating Instructions, 09/2018, A5E42603425-AA
7.3
Electrical configuration
Non-isolated configuration
Note
Unlike the ET 200SP distributed I/O system, the CPU
1515SP PC2 can only be operated
with a non
-isolated configuration.
