Technical specifications
12.4 Mechanical and climatic ambient conditions
CPU 1515SP PC2 (F/T/TF)
74 Operating Instructions, 09/2018, A5E42603425-AA
12.4
Mechanical and climatic ambient conditions
Note
Restrictions
In contrast to the ambient conditions for the ET
200SP distributed I/O system, the following
restrictio
ns apply to the CPU 1515SP PC2:
•
Mechanical ambient conditions:
– 2 g constant acceleration when using the BusAdapter BA 2×FC
•
Ambient temperature:
– 0 to 60 °C for horizontal installation with maximum 32 I/O modules
– 0 to 55 °C for horizontal installation with maximum 64 I/O modules
–
0 to 50 °C for vertical installation with maximum 32 I/O modules
Operating conditions
The CPU 1515SP PC2 is suitable for use in weather-proof, fixed locations. The operating
conditions are based on the requirements of DIN IEC 60721-3-3:
● Class 3M3 (mechanical requirements)
● Class 3K3 (climatic requirements)
Mechanical ambient conditions
The table below shows the mechanical ambient conditions in the form of sinusoidal
oscillations.
Table 12- 7 Mechanical ambient conditions
Frequency band
CPU 1515SP PC2
5 ≤ f ≤ 8.4 Hz
3.5 mm amplitude
8.4 ≤ f ≤ 150 Hz
1 g constant acceleration
10 ≤ f ≤ 60 Hz
0.35 mm amplitude
60 ≤ f ≤ 1000 Hz
• 1 g constant acceleration (with BusAdapter BA 2×RJ45)
• 2 g constant acceleration (with BusAdapter BA 2×FC)
