Technical specifications
12.4 Mechanical and climatic ambient conditions
CPU 1515SP PC2 (F/T/TF)
Operating Instructions, 09/2018, A5E42603425-AA
75
Test of mechanical ambient conditions
The table below provides important information with respect to the type and scope of the test
of ambient mechanical conditions.
Table 12- 8 Test of mechanical ambient conditions
Condition tested
Test Standard
Comment
Vibration Vibration test accord-
ing to IEC 60068-2-6
(sine)
Type of oscillation: Frequency sweeps with a rate of change of 1 oc-
tave/minute.
BA 2×RJ45
• 5 Hz ≤ f ≤ 8.4 Hz, 3.5 mm constant amplitude
• 8.4 Hz ≤ f ≤ 150 Hz, 1 g constant acceleration
BA 2×FC
• 10 Hz ≤ f ≤ 60 Hz, 0.35 mm constant amplitude
• 60 Hz ≤ f ≤ 1000 Hz, 2 g constant acceleration
Duration of vibration: 10 frequency sweeps per axis in each of 3 vertically
aligned axes
Shock Shock, tested accord-
ing to IEC 60068-2-27
Type of shock: Half-sine
Shock intensity: 150 m/s
2
peak value, 11 ms duration
Direction of shock: 3 shocks in each direction (+/-) at each of 3 vertically
aligned axes
Climatic ambient conditions
You can use the CPU 1515SP PC2 under the following climatic ambient conditions:
Table 12- 9 Climatic ambient conditions
Ambient conditions
Permissible range
Comments
Temperature:
Horizontal mounting position:
• from 0 to 60 °C
For configuration with 32 I/O modules
• from 0 to 55 °C
For configuration with 64 I/O modules
Vertical installation:
• 0 to 50 °C
For configuration with 32 I/O modules
Permitted temperature change
10 K/h
-
Relative humidity
from 10 to 95%
Without condensation
Barometric pressure From 1140 to 795 hPa Corresponds to an altitude of -1000 m
to 2000 m
Concentration of pollutants ANSI/ISA-71.04 severity level G1; G2;
G3
-
