Technical specifications
12.7 Module data
CPU 1515SP PC2 (F/T/TF)
78 Operating Instructions, 09/2018, A5E42603425-AA
12.7
Module data
12.7.1
Technical specifications of CPU 1515SP PC2 - basic device
Technical specifications
The following table shows the technical specifications as of 08/2018. You will find a data
sheet including daily updated technical specifications on the Internet
(https://support.industry.siemens.com/cs/ww/en/pv/6ES7677-2DB40-0AA0/td
).
Article number
6ES7677-2DB40-0AA0
General information
Product type designation
CPU 1515SP PC2
HW functional status
FS01
Firmware version
V2.5
Engineering with
• STEP 7 TIA Portal configurable/integrated
as of version
V15 with HSP 255
Installed software
• Visualization
No
• Control
No
Control elements
Mode selector switch
1
Supply voltage
Type of supply voltage
24 V DC
permissible range, lower limit (DC)
19.2 V
permissible range, upper limit (DC)
28.8 V
Reverse polarity protection
Yes
Mains buffering
• Mains/voltage failure stored energy time
5 ms
Input current
Current consumption (rated value) 1.8 A; Full processor load, incl. ET 200SP mod-
ules and using USB
Current consumption (in no-load operation),
typ.
0.5 A
I²t
0.426 A²·s; with starting current inrush
Power
Active power input, max.
43 W; incl. ET 200SP modules and using USB
Infeed power to the backplane bus
8.75 W
Power loss
Power loss, typ.
16 W
