Siemens SIMATIC CPU 1515SP PC2 F User Manual

Technical specifications
12.7 Module data
CPU 1515SP PC2 (F/T/TF)
Operating Instructions, 09/2018, A5E42603425-AA
79
Article number
6ES7677-2DB40-0AA0
Memory
Type of memory
DDR3L
Main memory
8 GB RAM
CFast memory card
No
SIMATIC memory card required
No
Hardware configuration
Integrated power supply
Yes
Number of DP masters
• Via CM
1
Rack
• Modules per rack, max.
64; CPU + 64 modules + server module (mount-
ing width max. 1 m)
Time of day
Clock
• Type
Hardware clock
• Backup time
6 wk; At 40 °C ambient temperature, typically
• Deviation per day, max.
10 s; Typ.: 2 s
Interfaces
Number of industrial Ethernet interfaces
2
Number of PROFINET interfaces
1
Number of PROFIBUS interfaces
1; Via CM DP module
Number of RS 485 interfaces
1; Via CM DP module
Number of USB interfaces
4; 2x USB 2.0, 2x USB 3.0 on front side
Video interfaces
• Graphics interface
1x DisplayPort
1. Interface
Interface types
• Number of ports
2
• integrated switch
Yes
• RJ 45 (Ethernet)
Yes; Via BusAdapter BA 2x RJ45
– Transmission rate, max.
100 Mbit/s
– Industrial Ethernet status LED
Yes
2. Interface
Interface types
• Number of ports
1
• RJ 45 (Ethernet)
Yes; Integrated
– Transmission rate, max.
1 000 Mbit/s
– Industrial Ethernet status LED
No
