Technical specifications
12.7 Module data
CPU 1515SP PC2 (F/T/TF)
80 Operating Instructions, 09/2018, A5E42603425-AA
Article number
6ES7677-2DB40-0AA0
Ambient conditions
Ambient temperature during operation
• min.
0 °C
• max.
Up to 60 °C with max. 32 ET 200SP modules and
3x 100 mA USB load; up to 55 °C with max. 64
ET 200SP modules and 2x max. 500 mA and 1x
max. 100 mA USB load
• horizontal installation, min.
0 °C
• horizontal installation, max.
60 °C
• vertical installation, min.
0 °C
• vertical installation, max.
50 °C; With max. 32 ET 200SP modules and 3x
100 mA USB load
Ambient temperature during stor-
age/transportation
• min.
-40 °C
• max.
70 °C
Peripherals/Options
Peripherals
• SD card
Optionally for additional mass storage
Dimensions
Width
160 mm
Height
117 mm
Depth
75 mm
Weights
Weight, approx.
0.83 kg
