Siemens SIMATIC CPU 1515SP PC2 F User Manual

Introduction
1.1 Documentation on CPU 1515SP PC2
CPU 1515SP PC2 (F/T/TF)
Operating Instructions, 09/2018, A5E42603425-AA
7
Conventions
STEP 7: In this documentation, "STEP 7" is used as a synonym for all versions of the
configuration and programming software "STEP 7 (TIA Portal)".
"CPU1515SP PC2 T" means that the respective section applies
only
to the
"CPU 1515SP PC2 T".
"CPU1515SP PC2 F" means that the respective section applies
only
to the
"CPU 1515SP PC2 F".
"CPU1515SP PC2 TF" means that the respective section applies
only
to the
"CPU 1515SP PC2 TF".
"CPU 1515SP PC2" also includes "CPU1 515SP PC2 F", "CPU 1515SP PC2 T" and
"CPU 1515SP PC2 TF".
Please also observe notes marked as follows:
Note
A note contains important information on the product described in the documentation, on the
handling of the product or on the section of the documentation to which particular attention
should be paid.
Scope of validity of the documentation
This documentation is valid for the following products:
ET 200SP Open Controller
Article number
Standard CPU
• CPU 1515SP PC2 basic device
6ES7677-2DB40-0AA0
• CPU 1515SP PC2
6ES7677-2DB42-0GB0
• CPU 1515SP PC2 + HMI 128PT
6ES7677-2DB42-0GK0
• CPU 1515SP PC2 + HMI 512PT
6ES7677-2DB42-0GL0
• CPU 1515SP PC2 + HMI 2048PT
6ES7677-2DB42-0GM0
Fail-safe CPUs
• CPU 1515SP PC2 F
6ES7677-2SB42-0GB0
• CPU 1515SP PC2 F + HMI 128PT
6ES7677-2SB42-0GK0
• CPU 1515SP PC2 F + HMI 512PT
6ES7677-2SB42-0GL0
• CPU 1515SP PC2 F + HMI 2048PT
6ES7677-2SB42-0GM0
Technology CPUs
• CPU 1515SP PC2 T
6ES7677-2VB42-0GB0
Fail-safe technology CPUs
• CPU 1515SP PC2 TF
6ES7677-2WB42-0GB0

Siemens SIMATIC CPU 1515SP PC2 F Specifications

General

Brand	Siemens
Model	SIMATIC CPU 1515SP PC2 F
Category	Control Unit
Language	English
