Technical specifications
12.7 Module data
CPU 1515SP PC2 (F/T/TF)
Operating Instructions, 09/2018, A5E42603425-AA
87
Article number
6ES7677-2DB42-0GK0
1. Interface
Interface types
• Number of ports
2
• integrated switch
Yes
• RJ 45 (Ethernet)
Yes; Via BusAdapter BA 2x RJ45
– Transmission rate, max.
100 Mbit/s
– Industrial Ethernet status LED
Yes
2. Interface
Interface types
• Number of ports
1
• RJ 45 (Ethernet)
Yes; Integrated
– Transmission rate, max.
1 000 Mbit/s
– Industrial Ethernet status LED
No
3. Interface
Interface types
• RS 485
Yes
RS 485
• Transmission rate, max.
12 Mbit/s
Interrupts/diagnostics/status information
Diagnostics indication LED
• RUN/STOP LED
Yes
• ERROR LED
Yes
• MAINT LED
Yes
Ambient conditions
Ambient temperature during operation
• min.
0 °C
• max.
Up to 60 °C with max. 32 ET 200SP modules and
3x 100 mA USB load; up to 55 °C with max. 64
ET 200SP modules and 2x max. 500 mA and 1x
max. 100 mA USB load
• horizontal installation, min.
0 °C
• horizontal installation, max.
60 °C
• vertical installation, min.
0 °C
• vertical installation, max.
50 °C; With max. 32 ET 200SP modules and 3x
100 mA USB load
Ambient temperature during stor-
age/transportation
• min.
-40 °C
• max.
70 °C
