Product overview
3.2 Properties
F-TM ServoDrive
18 Equipment Manual, 02/2020, A5E47579503-AA
Properties
The F-TM ServoDrive has the following properties:
● Operation on ET 200SP PROFINET IMs as of V4.0
● Operation on CPU 151x as of V2.0, S7-1200, OpenController and CPU 151xSP
● Speed-controlled single-axis drive with PROFIdrive profile
● Nominal voltage of the drive module: 24 to 48 V DC (safety extra-low voltage)
● Support of IQ-Encoder technology for easy commissioning
● 24 V digital input
● Support of individually configurable motors
● Controller parameter determination possible using HSP
● Thermal monitoring of the motor and the power end stage
● Braking chopper, external braking resistor
● Cyclic overload capability
● Safety function STO hardwired
● Integrated engineering in STEP 7 (TIA Portal) via Hardware Support Package HSP0311
● Support for commissioning through drive control panel and message buffer in the
engineering tool
Accessories
The following accessories, which are not included in the scope of delivery of this module,
can be used with the module:
● Labeling strips
● Color-coded labels
● Reference identification labels
● Shield connection
A BaseUnit of the type U0 (6ES7193-6BP00-0DU0 oder 6ES7193-6BP00-0BU0) is needed
for operation of the F-TM ServoDrive. You can find an overview of the BaseUnits that you
can use with the technology module in the manual SIMATIC ET 200SP BaseUnits
(https://support.industry.siemens.com/cs/ww/en/view/109751716
).
For more information on accessories, refer to the system manual SIMATIC ET200SP
distributed I/O system (https://support.industry.siemens.com/cs/ww/en/view/58649293
).
