Siemens SIMATIC ET 200SP F-TM User Manual

Commissioning the
7.4 Drive data sets
F-TM ServoDrive
64 Equipment Manual, 02/2020, A5E47579503-AA
You use "Response to max. temperature" to define the behavior that is triggered when the
maximum temperature is reached.
● Shutdown when temperature is exceeded Brake chopper operation is stopped and a
warning is generated.
● No shutdown when temperature is exceeded Brake chopper operation is still possible.
NOTICE
Risk of fire
If braking chopper operation continues despite reaching the maximum operating
temperature, this can result in a sharp increase in the temperature at the braking
resistor. This can damage surrounding components or even result in fires in the worst
case.
In addition, always ensure that the minimum distances between the braking resistor and
other modules are maintained.
CAUTION
Risk of burns due to hot surfaces
The braking resistor heats up during operation. Touching the hot braking resistor can result
in personal injury and burns.
Avoid contact with the hot braking resistor.
7.4.1 Using the drive data set
To configure a drive, you have the following options:
● Download preconfigured drive data sets as a file for selected motors from Siemens
Industry Online Support.
● Create a user-defined drive data record and configure your motor manually.
Note
In the F
-TM ServoDrive engineering, the drive parameters can only be edited in the
"Parameters" > "Drive" area if you are using a user
-defined drive data record.
NOTICE
After a change of the drive data record, you must adapt or optimize the parameters for the
current and speed controllers, if necessary.
See section Open-loop/closed-loop control (Page 71).
