Commissioning the
7.1 Basics
F-TM ServoDrive
58 Equipment Manual, 02/2020, A5E47579503-AA
Conditions
● When you load parameters into the device, a rotating drive automatically stops.
● After the parameters are loaded, the drive does not restart automatically. You need to
activate the drive via a new drive command.
● If you send an invalid parameter to the F-TM ServoDrive, the module remains in
parameter assignment mode. The drive cannot be activated until valid parameters are
loaded.
"Download to device" function for drive parameters
You can use the "Download to device" function to transfer parameter values from your
project (offline) to the drive (online).
Procedure
1. Select the drive in the project tree.
2. Click on "Download to device"
in the menu bar.
Or
1. Select "Download to device" > "Software" in the shortcut menu.
You have transferred the current parameter values of your project to the drive.
7.1.3 Calling help information
To obtain information on parameters and alarms (messages) of the drive, open the
information system via "Help" > "Show help" and search for the article number of the
product.
You can also directly open the information system for a parameter or a message. To do so,
click the online help link in the tooltip of a parameter or message
.
