Commissioning the
7.4 Drive data sets
F-TM ServoDrive
66 Equipment Manual, 02/2020, A5E47579503-AA
You have selected and set up a preconfigured drive data record.
Note
You can pass on a saved engineering project with preconfigured drive data record or use it
on a different PG/PC on which the utilized dr
ive is not installed. In this case, no optional
tional information on the drive is displayed, e.g. manufacturer or order number. This is
displayed as soon as you have installed the utilized drive.
7.4.3 Using a user-defined drive data set
Create a user-defined drive data record and configure your motor manually.
You can also use this function to edit an existing drive data record.
Avoiding incorrect parameter assignments
Note that incorrect or modified parameter assignments can result in drive malfunctions and
damage to the drive.
Procedure
To freely configure the current drive data, follow these steps:
1. Open "Parameters" > "Drive" in the context of the drive.
2. Start the configuration wizard with the "Configure drive data record…" button in the "Drive
data record" area.
3. Select the "Edit drive data record by user" option.
4. Accept the configuration with "Yes".
5. Confirm that you are changing the drive data record.
The current setting for the controller tuning is displayed.
To then change directly to the commissioning area, select the "Display commissioning"
option.
6. Adjust the motor settings for your drive.
Observe the information and notes in the help or in the tooltips of the individual
parameters.
You can also find detailed information and descriptions for the drive parameters in the
Product Information (https://support.industry.siemens.com/cs/ww/en/view/109773204
).
You have selected user-defined editing of the drive and adapted the settings.
