Commissioning the
7.6 Controller settings
F-TM ServoDrive
74 Equipment Manual, 02/2020, A5E47579503-AA
OFF2 (Coast down)
You activate OFF2 and the drive coasts down by resetting bit 1 in STW1 (NoCoastStop).
Note
NOTE on rapid stop (OFF3)
You trigger a quick stop (OFF3) by resetting bit 2 in STW1 (N
oQuickStop). The rapid stop
takes into account the ramp
-down time configured in the HSP ("Parameter" > "Setpoint
– Ramp generator"). The rapid stop is monitored for time and causes the
motor to be energized after 6 seconds at the latest.
Prioritization
The OFF responses are prioritized as follows:
● OFF2 (coast down) > OFF1 (switch off)
