Siemens SIMATIC ET 200SP F-TM User Manual

Programming
8.1 Controlling F-TM ServoDrive via the process image
F-TM ServoDrive
Equipment Manual, 02/2020, A5E47579503-AA
85
Element
Data type
Offset
Bit08_Reserved
Bool
6.0
Bit09_Reserved
Bool
6.1
Bit10_Reserved
Bool
6.2
Bit11_Reserved Bool 6.3
Bit12_Reserved
Bool
6.4
Bit13_Reserved
Bool
6.5
Bit14_Reserved
Bool
6.6
Bit15_Reserved
Bool
6.7
Bit00_Reserved
Bool
7.0
Bit01_Reserved
Bool
7.1
Bit02_Reserved
Bool
7.2
Bit03_Reserved
Bool
7.3
Bit04_Reserved
Bool
7.4
Bit05_Reserved
Bool
7.5
Bit06_Reserved
Bool
7.6
Bit07_Reserved
Bool
7.7
Encoder control word 1
Struct
8.0
Bit08_Reserved
Bool
8.0
Bit09_Reserved
Bool
8.1
Bit10_Reserved
Bool
8.2
Bit11_Reserved
Bool
8.3
Bit12_Reserved
Bool
8.4
Bit13_AbsoluteValueCyclically Bool 8.5
Bit14_RequestParkingEncoder
Bool
8.6
Bit15_AcknowlegdeError Bool 8.7
Bit00_Function1Request
Bool
9.0
Bit01_Function2Request
Bool
9.1
Bit02_Function3Request
Bool
9.2
Bit03_Function4Request
Bool
9.3
Bit04_Command0Request
Bool
9.4
Bit05_Command1Request
Bool
9.5
Bit06_Command2Request
Bool
9.6
Bit07_Mode
Bool
9.7
