Product overview
2.1 Properties
Technology module TM ECC 2xPWM ST (6FE1242-6TM10-0BB1)
Manual, 04/2018, A5E42681298B-AA
13
● 2x Control Pilot (CP)
● 2x Plug Present (PP)
● 2x Digital Out (DQ) as open collector
● 2x Digital In (DI)
● 2x connector for electromotive or electromagnetic connector locking (ACTp, ACTn)
You must not connect an external voltage to the PP connector, because it could destroy the
internal circuitry of the connector. This also applies if the module is operated in accordance
with the SAE J1772 standard. In this operating mode, you must
connect the PP
conductor to the module. This will result in an error message.
If you have configured the technology module with "electromagnetic connector locking", the
ACTn connector functions as open collector. The load (the locking electromagnets in this
case) connected to this connector must be supplied by a voltage source with limited voltage
and/or power rating (SELV, PELV according to EN61010-1 and EN61010-2-201, Class 2).
Maximum 12 V DC / 1.3 A.
In general, you must not connect an external voltage >12 V to the ACTp and ACTn
connectors.
Distributed operation in an S7-1500 system:
● TIA Portal as of version V14 SP1
Distributed operation in a system from a different manufacturer:
● PROFINET GSD files
(https://support.industry.siemens.com/cs/document/57138621?dti=0&lc=en-US)
The following accessories can be used with the module and is not included in the scope of
delivery:
● Labeling strips
● Color-coded labels
● Reference identification labels
A BaseUnit of the BU type B1 or BU type B0 is required to operate the technology module.
You can find an overview of the BaseUnits that are compatible with the technology module in
the Product information for documentation of the ET 200SP Distributed I/O System
(https://support.industry.siemens.com/cs/document/73021864?dti=0&lc=en-US).
