Product overview
2.1 Properties
Technology module TM ECC 2xPWM ST (6FE1242-6TM10-0BB1)
14 Manual, 04/2018, A5E42681298B-AA
You will find additional information on installation in the ET 200SP distributed I/O system
System Manual (https://support.industry.siemens.com/cs/document/58649293?dti=0&lc=en-
US).
Electric and electronic devices do not belong in household waste. Dispose of the product
according to the valid legal regulations at the end of its service life. By doing so you will meet
the legal obligations and help protect the environment. WEEE Reg. No. DE 23691322
The charging controller described here is a technology module for SIMATIC ET 200SP.
Solutions for S7-1500 CPUs are possible. TIA Portal can be used as the configuration
software.
Figure 2-2 Configuration example with one charging outlet
