Circuit diagram example

4.4 TIA Portal configuration

Safety engineering with AS‑Interface in the SIMATIC ET 200SP, including typical circuit diagram

46 Function Manual, 08/2020, A5E44991382002A/RS-AB/002

Transfer the code sequences with the "TEACH" button:

As an alternative, the "TEACH" button can be used to provide an easy way of transferring

taught code sequences. The "TEACH" button can be used, for example, to transfer code

sequences of modules replaced during operation. However, it is also suitable for initial

commissioning.

The "TEACH" pushbutton is connected to the terminals "TEACH1" and "TEACH2" (terminals 1

and 2) of the base unit of the F-CM AS-i Safety ST module.

Press the "TEACH" button for at least 3 s. This action causes all currently taught code

sequences that are unique and consistent to be transferred to the non-volatile memory. Next,

the input data of the safe AS-i input slaves is evaluated, allowing reintegration in the safety

program.

Further information on the topic of code sequences can be found in the "T 200SP fail-safe

module F-CM AS-i Safety ST

(https://support.industry.siemens.com/cs/ww/de/view/90265988)" Manual in the "Code

sequences" section.
