Siemens simatic et200sp Function Manual

Circuit diagram example
4.5 TIA Portal programming
Safety engineering with AS‑Interface in the SIMATIC ET 200SP, including typical circuit diagram
Function Manual, 08/2020, A5E44991382002A/RS-AB/002
49
The values in the DataToSafety data block are written by the standard user program and read
by the safety program. The values in the DataFromSafety data block are written by the safety
program and read by the standard user program. Since this example does not contain a
standard user program, these two global data blocks were not included. They should be
added by the user of this example.
Note
Further information on the data exchange between standard user program and
safety
program can be found in the "SIMATIC Safety
- Configuring and Programming" Manual.
(https://support.industry.siemens.com/cs/ww/en/view/54110126)

Siemens simatic et200sp Specifications

General

Category	I/O Systems
Power Supply	24 V DC
Protection Rating	IP20
Number of Modules	Up to 64 modules
Mounting	DIN Rail
Communication Protocols	PROFINET, PROFIBUS
Storage Temperature	-40 °C to +70 °C
Digital Inputs	Yes (depending on module)
Digital Outputs	Yes (depending on module)
Analog Inputs	Yes (depending on module)
Analog Outputs	Yes (depending on module)
Modularity	Modular
Relative Humidity	5 to 95% (non-condensing)
Weight	Varies by configuration
System Type	Distributed I/O
