Siemens SIMATIC HMI KTP700F Mobile Arctic User Manual

KTP700F Mobile Arctic
A5E49199858-AB, 02/2021
15
Certificates and approvals
The device is certified as shown on the rear of the device.
Technical specifications
This section contains the technical specifications of the KTP700F Mobile Arctic, which differ from the technical specifications
of the KTP700F Mobile.
You can find all other specifications in the "Mobile Panels 2nd Generation" operating instructions.
Mechanical system
KTP700F Mobile Arctic
Weight without packaging
1435 g
Weight with packaging
1640 g
Height of fall
1.2 m
Display
KTP700F Mobile Arctic
Type
LCD TFT
Active display area
152 mm x 91 mm
Display diagonal
7.0"
Resolution
800 × 480 pixels, widescreen
Number of colors
Up to 16 million
Brightness control
By software
Backlighting
Half Brightness Life Time (MTBF
1
)
LED
50000 h
Pixel error class in accordance with EN ISO 9241-307
I
1
Operating hours after which the maximum brightness is reduced by half compared to the original value. MTBF is
increased by using the integrated dimming function, for example, time-controlled via screen saver or centrally via
PROFIenergy.
Input device
KTP700F Mobile Arctic
Type
Touch screen, analog resistive
surface
GFG (glass film glass) touch
Function keys
8
Labeling strips
No
Connecting cable
Bending radius, minimum
≥ 4-times the outside diameter of the line
Rated condition, temperature
See section "Climatic ambient conditions (Page 16)"
Connection boxes
The connection boxes are approved for the following temperature ranges:
Connection box
Permissible standard temperature range
1
"Arctic" extended operating temperature range
2
compact
X
X
standard
3
X
-
advanced
X
X
1
See section "Climatic ambient conditions" in the underlying Operating Instructions.
2
See section "Climatic ambient conditions (Page 16)".
3
See note in the section "Connection boxes (Page 11)".
