KTP700F Mobile Arctic
16 A5E49199858-AB, 02/2021
Climatic ambient conditions
Operating Conditions
The following information applies to the HMI device, the connection boxes and connecting cables. The devices are designed
for operation in a location protected from the effects of the weather.
Contrary to what is stated in the operating instructions of the basic unit: The connection boxes from section "Connection
boxes (Page 11)" and connecting cables from section "Connecting Cable (Page 11)" are released for the extended operating
temperature range "Arctic" in combination with the HMI device.
Type of condition
Permitted range
Comment
Temperature, HMI device
-28 °C to 45 °C
Extended operating temperature range "Arctic"
Temperature, connection boxes
-28 °C to 55 °C
Atmospheric pressure
1140 hPa to 795 hPa
corresponds to an elevation of -1000 m to 2000 m
Relative humidity
10% to 90%
1
No condensation
1
1
HMI device, connection box, Advanced: No condensation inside the enclosure.
Connection box compact: No condensation on the rear
Note
Condensation endangers the interior of the device
After transporting the HMI device at low temperatures or if the HMI device has be
en exposed to temperature fluctuations,
moisture can condense on the HMI device or inside the device (condensation). The device can be damaged with
consequences for the machine or plant.
•
Let the HMI device warm up to room temperature before switching it on.
•
Do not expose the HMI device to direct radiation from a heater to warm it up.
• In case of condensation, dry the HMI device completely or switch it on only after a waiting period of about 4 hours.
Technical Support
You can find technical support for your device by entering the MLFB under:
• Technical support (https://support.industry.siemens.com/cs/ww/en/)
KTP700F Mobile Arctic
A5E49199858-AB, 02/2021
Siemens AG
Digital Industries
Postfach 48 48
90026 NÜRNBERG
GERMANY
