Service and maintenance
8.5 Module replacement
SIMATIC RF360R
100 Configuration Manual, 03/2022, C79000-G8976-C629-02
8.5.1 Backup configuration data
Table 8- 6 Properties and requirements for the backup options
• Module replacement possible without PG
• Automatic sequence possible
⇒ The automatic sequence needs to be programmed by the user.
Backup in the STEP 7 project
• Download to the reader only possible manually in STEP 7
• No management of configuration versions
⇒ Only the last version is ever stored (no storage of older
versions).
⇒ You need to update the configuration version in the project
Backup via the WBM (as *.xml
file)
• Configuration data is saved regardless of the project and
controller
⇒ The download to the reader can be performed manually using
the WBM via user application.
• Option of copying for other readers of the same type
• Older configuration versions can be saved (versioning)
⇒ The updating and versioning of the configuration versions
needs to be started and managed manually by you yourself.
Backup on the controller
Using the "Config_Upload" and "Config_Download" blocks, you can read out
("Config_Upload") or write ("Config_Download") the configuration of the readers via the
control program. Since the configuration is stored permanently, you need to reserve a data
block/a variable for this in the controller.
To check the correct configuration, you can read out the version ID (Config ID) of the reader
with the reader status and compare this to the Config ID that was stored in the controller
earlier with the "Config_Upload" command in the data block / in the variable.
You can find more information on programming the blocks and the structure of the
configuration data in the section "Config_Upload/-_Download" of the manual "Ident profile
and Ident blocks, standard function for Ident systems
(https://support.industry.siemens.com/cs/ww/en/view/109793329)".
