Configuring with the WBM
6.3 The menu items of the WBM
SIMATIC RF360R
Configuration Manual, 03/2022, C79000-G8976-C629-02
43
Log settings
In the "Log settings" area, you can use the check boxes to decide which events are entered in
the log. The log is structured as a circular buffer. Bear in mind that with a high degree of
detail of the data, the circular buffer fills up more quickly which can have a negative effect on
the performance of the device.
Table 6- 3 Description of the parameters of the log
Messages relating to general events:
e.g. reader startup, login to the WBM, ...
Error and alarm messages of the reader
Recording of all tag events
Commands of the user application
Return values for the commands of the user application and for the written or
read transponder data.
Call parameters for the commands of the user application
Recording of the status frames for PLC communications. Can be switched off if
the status frames are used as line monitoring. In this way, the logbook is kept
Service logbook settings
In the "Service logbook settings" area, you can use the check boxes to decide which events
are entered in the Service logbook. The Service logbook is structured as a ring buffer. Bear in
mind that with a high degree of detail of the data, the ring buffer fills up more quickly, which
can have a negative effect on the performance of the device.
Table 6- 4 Description of service logbook parameters
Frames on the XML interface
Internal frames on the PLC interface
Internal frames to the Web server
Frames on the internal interface
Recording of the line monitoring frames (CMD_XML and CMD_PLC) for service
information. Can be switched off to keep the logbook free for payload data.
