Configuring with the WBM
6.3 The menu items of the WBM
SIMATIC RF360R
Configuration Manual, 03/2022, C79000-G8976-C629-02
45
If you have set the "RF360R" parameter value in the "Ident devices/system" parameter, you
can configure the following reader parameters.
Table 6- 6 Parameters in the "Reader parameters" parameter group
Parameter
Parameter value
Default value
Description
Presence check
On
Off (RF field on)
Off (RF field off)
On
On = As soon as there is a transponder in the
antenna field of the reader, its presence is
reported.
Off (RF field on) = the presence check in the FB
is suppressed. The antenna on the reader is
nevertheless turned on as long as it has not
been turned off by a command.
Off (RF field off) = The antenna is turned on
only when a command is sent and it then turns
itself off again.
Reset error LED
Off
On
On
Off = The error LED always indicates the last
error. The display can only be reset by turning
off the reader.
On = The flashing of the error LED on the reader
is reset by each reset and by a new OPC
command.
Off
After a successful
command:
After a reset command
After a reset or a
successful command
Off = The flashing LED is not reset in the event
of an error, even by switching off the power
supply to the reader.
After a successful command = The flashing of
the LED in the event of an error is reset after the
successful execution of a command. This only
affects communication errors.
After a reset command = The flashing of the LED
in the event of an error is reset by a "init_run" or
"WRITE-CONFIG" with "Init" (RESET).
After a reset or a successful command = The
flashing of the LED in the event of an error is
reset by a "init_run" or "WRITE-CONFIG" with
"Init" (RESET) or after the successful execution
of a command.
ECC mode
On
Off
Off
Activation/deactivation of ECC mode. Detailed
information about the mode can be found in
the product information "Input parameters for
the RF300 system for programming via
communication modules".
Requirement: Transponder type: ISO 15693 =
None
Semaphore procedure
On
Off
Off
Activation/deactivation of the semaphore
procedure. You can find detailed information on
the procedure in the product information "Input
parameters for the RF300 system for
programming via communication modules".
Requirement: Transponder type: ISO 15693 =
None
Transponder type
1)
1)
Selection of the transponder types used.
1)
You can find a detailed description of these parameters in the following paragraphs.
