Service and maintenance
8.2 Error messages
SIMATIC RF360R
86 Configuration Manual, 03/2022, C79000-G8976-C629-02
Flashin
g of the
reader
Block (hex) Error description
There is more than one transponder in the transmission window.
The file name is not allowed.
Warning in the event of low power supply
The power supply is very close to the low limit.
Connection problem with the reader
Error in the connection to the reader; the reader is not answering.
Possible causes / action to be taken:
• The PROFINET or power supply cable is wired incorrectly or there is a cable break.
• The 24 V supply voltage is not connected or is not turned on or has failed briefly.
• The hardware is defective.
• RF300: Antenna is not identified
Possible causes: Antenna is not connected or antenna cable is defective.
Perform an "init_run" once the error has been corrected.
The buffer on the communications module or reader is not adequate to store the command
temporarily.
The buffer on the communications module or reader is not adequate to store the data
temporarily.
The command is not permitted in this status or is not supported.
Possible causes:
• The "INIT" command has been concatenated.
• Command repetition was started without "Presence mode".
Startup message from reader/communications module
The reader or communications module was off and has not yet received a "Reset_Reader"
("WRITE-CONFIG") command.
Possible causes / action to be taken:
• Execute the "INIT" command.
• The same physical address in the "IID_HW_CONNECT" parameter is being used more than
once. Check your "IID_HW_CONNECT" parameter assignments.
• Check the connection to the reader.
The device has not yet been restarted after the change to the transmission speed.
The specified tag field of the transponder is unknown.
No or bad configuration data/parameters were transferred.
Possible causes:
You are accessing a read point that is not configured.
