Service and maintenance
8.2 Error messages
SIMATIC RF360R
Configuration Manual, 03/2022, C79000-G8976-C629-02
89
Flashin
g of the
reader
Block (hex) Error description
• A parameter of an XML command has an invalid value or the parameter assignment of the
communications module or the reader was incorrect.
Possible causes / action to be taken:
– Check the parameters in the Ident profile.
– Check the relevant XML command.
– Check the parameter assignment in HW Config / STEP 7 (TIA Portal).
– The "WRITE-CONFIG" command has incorrect parameter settings.
– After a startup, the reader or communications module has still not received an "INIT".
• The parameter assignment of the reader or communications module on PROFIBUS/PROFINET
was incorrect and the command cannot be executed.
Possible causes / action to be taken:
– Length of the input/output areas is too small for the cyclic I/O word.
– Check whether you have used the correct GSD file.
– Command (e.g. "READ") issued with excessively long user data.
• Error when processing the command.
Possible causes / action to be taken:
– The data in "AdvancedCmd" or "IID_CMD_STRUCT" is incorrect (e.g. "WRITE" command
with length = 0).
Check "AdvancedCmd" or "IID_CMD_STRUCT" and execute an "INIT".
– The hardware of the reader/communication module is defective. The reader or
communications module receives bad data with an "INIT".
– Inconsistent length specifications in the command
• The wrong reset block was selected.
Possible causes / action to be taken:
–
Regardless of the selected reader system, use the "Reset_Reader" function block.
A transponder has passed through the transmission window of a reader without being
processed.
• This error message is not reported immediately. Instead, the reader or communications
module waits for the next write / read command. This command is replied to immediately
with this error and the write/read command is not executed. The next command is executed
normally again by the reader/communications module.
• You can reset this error status using an "INIT".
Bit 2 is set in the "OPT1" parameter and there is no transponder in the transmission window.
An error has occurred that makes a Reset_Reader ("WRITE-CONFIG" with "Config = 3") necessary.
Possible causes / action to be taken:
• The "WRITE-CONFIG" command is incorrect.
• After eliminating the error, execute an "INIT".
Check the parameter "IID_HW_CONNECT".
