Siemens SIMATIC Ident User Manual

Connecting hardware
3.1 The PC adapter for SIMATIC RF-DIAG
SIMATIC RF-DIAG
18 Operating Manual, 09/2012, C79000-G8976-C292-01
3.1.4 Dimension drawing


 
Figure 3-2 Dimension drawing of the PC adapter for SIMATIC RF-DIAG (all dimensions in mm)
When the USB protective cap is screwed on, the length of the adapter is 134 mm. The
tolerances are +/- 1 mm.
