Operating the software
5.3 The tabs of the RF640R/RF670R readers
SIMATIC RF-DIAG
32 Operating Manual, 09/2012, C79000-G8976-C292-01
5.3 The tabs of the RF640R/RF670R readers
Note
Configuration of the RF640R/RF670R readers is possible only using the RF-MANAGER
Basic
If an RF640R/RF670R reader is connected, the data sources can only be configured with the
RF-MANAGER Basic. The SIMATIC RF-DIAG diagnostics tool only accesses the
configuration loaded on the reader.
5.3.1 The "Info" tab
With the functions on the "Info" tab, you can establish the connection to the reader. This tab
is always displayed regardless of the connected reader type or the current connection status.
Following successful connection establishment to a reader, important basic information of
the reader is displayed.
Figure 5-1 The "Info" tab following successful connection establishment to an RF670R
