Software installation
4.3 Starting the software
SIMATIC RF-DIAG
Operating Manual, 09/2012, C79000-G8976-C292-01
25
4.3 Starting the software
Once you have copied the diagnostics tool, you can start SIMATIC RF-DIAG by double-
clicking on the "SIMATIC_RF-DIAG.exe" file. After starting the software, the user interface of
the diagnostics tool appears:
The 3 areas of the software user interface
Status area
Reader-specific functionalities
Protocol area
Figure 4-1 User interface of the SIMATIC RF-DIAG software
