Description
2.3 Components of the product and ordering data
SIMATIC RF-DIAG
Operating Manual, 09/2012, C79000-G8976-C292-01
9
2.3 Components of the product and ordering data
Components of SIMATIC RF-DIAG
● CD with SIMATIC RF-DIAG software, USB driver and documentation
● PC adapter for SIMATIC RF-DIAG for connecting the SIMATIC RF readers to SIMATIC
RF-DIAG software
● RS-422 cable, length 2 m
● USB connecting cable (USB 2.0 standard A at PC end to USB 2.0 mini-B at adapter end),
length 1.8 m
Ordering data
Product Order number
SIMATIC RF-DIAG 6GT2080-3GA00
Accessories for SIMATIC RF-DIAG
Adapter cable for wide-range power supply
24 VDC connecting cable for PC adapter for SIMATIC RF-
DIAG, length 5 m
6GT2891-0PH50
RS-422 cable, length 2 m (spare part) 6GT2891-4FH20
Wide-range power supply unit for SIMATIC RF systems
(100 - 240 VAC / 24 VDC / 3 A)
with 2 m connecting cable with country-specific plug
EU: 6GT2898-0AA00
UK: 6GT2898-0AA10
US: 6GT2898-0AA20
