Connecting hardware
3.1 The PC adapter for SIMATIC RF-DIAG
SIMATIC RF-DIAG
16 Operating Manual, 09/2012, C79000-G8976-C292-01
3.1.3 Technical specifications
Table 3- 7 Mechanical data
Property Description
Weight 310 g
Dimensions (L x W x H) 101 × 63 × 35 mm
Enclosure material Aluminum (painted)
Housing color Black
Installation No securing aids
Interfaces
RS422
• 1 x pin (8-pin M12, connection to CM/wide-range power supply)
• 1 x socket (8-pin M12, connection to the reader)
USB USB 2.0 Mini-B
MTBF in years 1.1x10
3
Table 3- 8 Software interfaces
Property Description
Software – RS-422 SIMATIC S7 / TIA
Software – USB
• RF600 • 3964R & RF-DIAG
Table 3- 9 Electrical data
Property Description
Power supply of the PC adapter via USB
(during operation)
• Nominal value
• Permitted range
• 5 V DC
• 4.0 to 5.25 VDC
Power supply of the RF readers via RS-422
• Nominal value
• Permitted range
• 24 VDC
• 20 to 30 VDC
Current consumption
• Connection via USB and RS-422
• No connection via USB
• Via 5 VDC, approx. 30 mA; 24 VDC, approx. 15 mA
• Via 24 VDC, ≤ 5 mA
Transmission rates USB / RS-422
• 19.2 Kbps
• 57.6 Kbps
• 115.2 Kbps
