Siemens SIMATIC IFP1200 Basic

Technical information
7.5 Technical specifications
IFP Basic
Operating Instructions, 06/2023, A5E46178354 - AD
71
Tested for
Test standard
Comments
Vibrations
Vibration test in accordance
with IEC 60068, part 2-6 (si-
nusoidal)
Type of vibration:
Frequency cycles at a rate of change of
1octave/minute.
10 to 500 Hz, constant acceleration 3g
Vibration duration:
10 frequency cycles per axis in each of the three mu-
tually vertical axes
Shock
Shock test in accordance with
IEC 60068, Part 2-27
Type of shock: Half-sine
Severity of shock:
Peak value 15 g, duration 11 ms
Direction of shock:
3000 shocks in ± direction of axis in each of the three
axes vertical to each other
Climatic ambient conditions
The following table shows the climatic ambient conditions for operation of the device.
Ambient conditions
Permitted range
Comments
Temperature for IFP1200 /
IFP1500 / IFP 1900 Basic:
• horizontal mounting
0 to 45 °C
• Vertical mounting
0 to 45 °C
Tilt angle max.
45°
Note:
Tilt angle is
only supported
for the horizon-
tal mounting.
Temperature for IFP2200
Basic:
• horizontal mounting
0 to 40 °C
• Vertical mounting
0 to 40 °C
Tilt angle max.
45°
Temperature for IFP1200
Basic C:
• horizontal mounting
0 to 60 °C
• Vertical mounting
0 to 50 °C
Tilt angle max.
45°
Relative humidity
10 to 85% at 30 °C, no condensation
Atmospheric pressure,
operation elevation
1140 to 700 hPa
Corresponds to an elevation
of -1000 to 3000 m
Multiplication factors for equipment ambient temperature of operation at altitudes up to 3000m,
tested in accordance with IEC 61131-2:2017
Altitude
Derating ratio for temperature
1
0 to 2000 m
2
1.0
3000 m
0.9
1
: Equipment ambient temperature rating at 2000 m.
