Siemens SIMATIC IFP1200 Basic

Technical information
7.5 Technical specifications
IFP Basic
Operating Instructions, 06/2023, A5E46178354 - AD
73
Radiated emission (emitted interference)
1 GHz to 3 GHz
< 76 dB peak and < 56 dB average
3 GHz to 6 GHz
< 80 dB peak and < 60 dB average
30 MHz to 230 MHz
< 40 dB (μV/m) quasi-peak
230 MHz to 1000 MHz
< 47 dB (μV/m) quasi-peak
Emission of radio interference voltages
0.150 MHz to 0.5 MHz
< 79 dB quasi-peak and < 66 dB average
0.5 MHz to 30 MHz
< 73 dB quasi-peak and < 60 dB average
7.5.2.4 Information on protection class and degree of protection
Protection class
Protection Class III in accordance with IEC 61010-1, for example. with protective conductor.
Protection against foreign objects and water
For the device IFP Basic, the information on degree of protection is as follows:
Degree of protec-
tion
Explanation
Front
When mounted:
• IP65 according to IEC 60529
1
Rear
• IP40 for IFP1200 Basic, IFP1500 Basic, IFP1900 Basic
2
• IP20 for IFP2200 Basic
2
1
The degree of protection of the front panel can only be guaranteed if the mounting seal
is properly installed at the cabinet.
2
The degree of protection of the rear panel can only be guaranteed when all the interface
are plugged in.
The degree of protection for the device IFP1200 Basic C is as follows:
• IP65 according to IEC 60529
Degree of pollution and overvoltage category
The device IFP Basic and IFP Basic C meets the following requirements according to IEC/UL
61010-2-201:
Degree of pollution
2
Overvoltage category
II
