Siemens SIMATIC IFP1200 Basic

Technical information
7.5 Technical specifications
IFP Basic
Operating Instructions, 06/2023, A5E46178354 - AD
69
7.5.2 Ambient conditions
7.5.2.1 Transport and storage conditions
Proper transport and storage, installation and assembly as well as careful operation and
maintenance are prerequisites for trouble-free and safe operation of the device.
Non-compliance with these regulations shall render the device warranty void.
Mechanical transport and storage conditions
The following information is for a device that is transported and stored in its original
packaging.
The device meets the requirements according to EN/IEC 61131-2 with the following
amendments and limitations:
Type of condition
Permitted range
Free fall
≤ 1 m
Vibration according to IEC 60068-2-6
5 to 8.4 Hz, deflection 3.5 mm
8.4 to 500 Hz, acceleration 1 g
Shock according to IEC 60068-2-27
250 m/s
2
, 6 ms, 1000 shocks
Climatic transport and storage conditions
The following information applies to a device that is transported in the original packaging
and weather-proof packaging, and stored from some time.
The device meets the requirements according to EN/IEC 61131-2 with the following
amendments and limitations:
Type of condition
Permitted range
Temperature
IFP Basic: –20 to 60 °C
IFP1200 Basic C: –20 to 70 °C
Atmospheric pressure,
altitude
1140 to 660 hPa, corresponds to an elevation of -1000 to 3500 m
Relative humidity
5% to 95% at 25/55 °C, no condensation
Note
If dewing has developed, wait until the HMI device has dried completely before switching it
on.
Do not expose the HMI device to direct radiation from a heater.
