Siemens SIMATIC IFP1200 Basic

Technical information
7.5 Technical specifications
IFP Basic
68 Operating Instructions, 06/2023, A5E46178354 - AD
SIMATIC IFP1200 Basic
SIMATIC IFP1200 Basic C
SIMATIC IFP1500
Basic
SIMATIC IFP1900
Basic
SIMATIC IFP2200
Basic
Backlighting
Half Brightness Life Time
(MTBF
1
)
LED
50000 h
LED
30000 h
Pixel error class in ac-
cordance with
ISO 9241-307
II
1
MTBF: Operating hours after which the maximum screen brightness is reduced by half compared to the original value.
MTBF is increased by using the integrated dimming function, for example time-controlled via screen saver or centrally
via PROFIenergy.
Input device
SIMATIC IFP1200
/ IFP1500
/ IFP1900
/ IFP2200
Basic and SIMATIC IFP1200 Basic C
Keyboard
Externally via USB
Touch screen
Analog resistive single touch screen
Interfaces
USB Type A, rear
USB Type B, rear
DisplayPort
VGA
SIMATIC IFP1200 / IFP1500 / IFP1900
/ IPF2200 Basic
2
1
1
1
SIMATIC IFP1200 Basic C
1
1
1
0
1
USB type A, maximum load 500 mA, equivalent to USB standard 2.0
DC power supply
SIMATIC IFP1200
Basic
SIMATIC IFP1500
Basic
SIMATIC
IFP1900 Basic
SIMATIC IFP2200
Basic
SIMATIC
IFP1200 Basic C
Rated voltage
Permitted voltage
range
24 V DC
+20.4 V to + 28.8 V
Inrush current I
2
t
Maximum 2.5 A, 15 ms
Power consumption
1
13 W 17 W 25 W 24 W 11 W
Maximum input
current
2.0 A at 24 V
Maximum permitted
transients
35 V (500 ms)
Minimum time be-
tween two transi-
ents
50 s
Internal protection
Electronic
1
The power loss generally corresponds to the specified value for power consumption.
