Technical specifications
7.4 Technical data
SIMATIC IPC227E
Operating Instructions, 11/2016, A5E35782395-AB
101
COM
• RS 232
1
, max. 115 Kbps, D-sub connector, 9-pin
• RS 485
1 2
/RS 422
1
(optional), max. 115 Kbps, D-sub con-
nector, 9-pin
USB 3 × USB 2.0, high speed/high current,
maximum of 2 can be operated in high-current mode at the
same time, max. 6 W
1 × USB 3.0, high current
You can find additional information in the section "Power re-
quirements of the components".
LAN interface X1 P1, RJ45
3
Intel LAN Controller Springville i210
10, 100, 1000 Mbps, teaming
4
LAN interface X2 P1, RJ45
3
Intel LAN Controller Springville i210
10, 100, 1000 Mbps, teaming
4
In the BIOS setup, you can configure support for RS232 or RS22/RS485 for each COM port.
Available parameters:
- Autodirection
- Onboard termination
- Half-duplex or Full-duplex
Termination can be set in BIOS.
For unique labeling, the LAN interfaces are numbered on the enclosure. The numbering by the
operating system can differ.
Teaming can be set and initiated in the configuration interface. In teaming operation, jumbo
frames, e.g. for the camera application, are not supported
Teaming is not possible in connection with Windows 10.
Permitted mounting positions (Page 29)
