SIMATIC IPC227E
Operating Instructions, 11/2016, A5E35782395-AB
55
Expanding and assigning parameters to the device
Open the device
Requirement
● The device is disconnected from the power supply.
● All connecting cables on the device have been removed.
● The device has been removed from the cabinet.
● A T20 screwdriver
Procedure - opening the device
Note
On the basic device the drive is located on the underside of the rear panel.
Carefully open the device.
You can not lay down the rear panel because of the drive's connecting cable.
The rear panel can only be completely removed after disconnecting the connection plug.
Read the information in section "Replacing the drive of a basic device (Page 68)".
