Technical specifications
7.5 Hardware descriptions
SIMATIC IPC227E
118 Operating Instructions, 11/2016, A5E35782395-AB
7.5.5.5
Battery status register (read-only, address 50Ch)
The status of the CMOS battery is monitored; the status (two-tier) can be read from the
battery status register.
Meaning of the bits
Battery status register (read-only, address 404Dh)
Bit
Meaning
7
6
5
4
3
2
1
0
0
0
CMOS battery capacity is still sufficient.
0 1 CMOS battery capacity is exhausted (remaining capacity is
sufficient for approx. one month)
1
1
CMOS battery is empty
7.5.5.6
NVRAM address register
NVRAM occupies a 512 KB memory address area that can be read via PCI registers.
Meaning of the bits
NVRAM address register
PCI register address:
NVRAM base address regis-
ter
PCI register content:
NVRAM memory address (default
setting)
Length of the memory area
9060 0000h Address is assigned dynamically
(depending on device configura-
tion)
80000 h
