Page #106 background imageLoading...
Page #106 background image
Technical specifications
7.5 Hardware descriptions
SIMATIC IPC227E
106 Operating Instructions, 11/2016, A5E35782395-AB
7.5
Hardware descriptions
7.5.1
Technical features of the motherboard
Component /
port
Description
Parameters
Chipset
integrated in CPU
BIOS Core, Video, ACPI
CPU
Intel Celeron N2930 / N2807
Memory DDR3L SODIMM 2 GB, 4 GB and 8 GB
Graphics Integrated graphics up to 512 MB graphics memory taken
dynamically from RAM
7.5.2
External interfaces
7.5.2.1
Overview of interfaces
Interface
Position
Description
COM External 9-pin D-sub, either:
RS 232
RS 485/RS 422
configurable in
BIOS Setup
CFast
External
CFast card
USB External 4 USB channels 3 × USB 2.0
1 × USB 3.0
Ethernet
External
2 x RJ45
10/100/1000 Mbps
DisplayPort
External
DP
