Technical specifications
7.4 Technical data
SIMATIC IPC227E
Operating Instructions, 11/2016, A5E35782395-AB
103
Mechanical ambient conditions
Vibration resistance Tested in accordance with IEC 60068-2-6
Operation With CFast card or SSD:
• 5 to 9 Hz: 3.5 mm
• 9 to 500 Hz: 9.8 m/s
2
With CFast card or SSD and standard rail:
• 10 ... 58 Hz: 0.075 mm
• 58 ... 200 Hz: 4.9 m/s
2
With hard disk and wall or upright mounting:
• 10 to 58 Hz: 0.0375 mm
• 58 to 200 Hz: 4.9 m/s²
With hard disk and standard rail mounting:
No excitation allowed
Storage/transport
• 5 to 9 Hz: 3.5 mm
• 9 to 500 Hz: 9.8 m/s
2
Impact resistance
Tested in accordance with IEC 60068-2-27
Operation
• Without hard drive: 150 m/s
2
, 11 ms
• With hard disk: 50 m/s
2
, 30 ms
Storage/transport
250 m/s
2
, 6 ms
