Installing and connecting the device
3.3 Connecting the device
SIMATIC IPC227E
42 Operating Instructions, 11/2016, A5E35782395-AB
Procedure
Switch off the 24 VDC power supply.
Connect the cores of the power supply.
Insert the terminal at the indicated pos
i
tion.
