User tasks
4.7 Creating a system image
SIMATIC IPC427C Bundles, SIMATIC HMI IPC477C Bundles
Manual, 07/2009, A5E02280126-02
39
4.7 Creating a system image
After you have configured the SIMATIC Embedded Bundle for your application, you can
create an image of your system. You can use this image later to restore your custom
application to your system, if necessary.
Create the system image (custom restore DVD) after you have performed any customization
tasks required by your application, such as those listed below:
● Download of a STEP 7 user program and configuration of WinAC RTX
(SIMATIC IPC427C-RTX/ -HMI/RTX or SIMATIC HMI IPC477C-RTX/ -HMI/RTX only)
● Transfer of a WinCC flexible project
● Configuration of WinAC Data Storage (SIMATIC IPC427C-RTX/ -HMI/RTX or
SIMATIC HMI IPC477C-RTX/ -HMI/RTX only)
● Modification of the initial configuration from the Station Configuration Editor
● Installation of any custom software or data files
NOTICE
You cannot recover the pre-installed WinAC RTX license key on the
SIMATIC Embedded Bundle from the custom restore DVD. Use the Automation License
Manager to remove the WinAC RTX license key, as well as any other SIMATIC license
keys, prior to making a custom restore DVD. Also note that if you plan to use the custom
restore DVD for more than one installation, each SIMATIC license key is valid for one
and only one computer.
Use the Image Creator to make your system image. The Image Creator is part of the tool
"SIMATIC PC/PG Image and Partition Creator" available from Siemens. You can find
ordering information for the Image Creator in the A&D Mall.
(http://mall.automation.siemens.com/
) Refer to the Image Creator instructions for additional
help on making and restoring system images.
