Initial startup
3.4 Pre-configurations
SIMATIC IPC427C Bundles, SIMATIC HMI IPC477C Bundles
18 Manual, 07/2009, A5E02280126-02
3.4 Pre-configurations
3.4.1 General information
After the calibration of the Touch Screen the pre-configurations are available.
Notes on all pre-configuration
The following information applies to all pre-configurations.
NOTICE
The Windows Firewall is enabled. All necessary SIMATIC protocols are registered as
exceptions. You can use the CP 5611 or the Industrial Ethernet interface to download
STEP 7 projects.
You do not have to perform any additional configuration in the PC Station or in WinLC
Properties. WinLC RTX submodules communicate in the RTX environment, and the
PC Station components communicate in the Windows Embedded environment.
NOTICE
If for any reason you need to reconfigure your PC Station with the Station Configuration
Editor, you must choose "IE General" for the Industrial Ethernet interface.
You can connect other devices such as a mouse, keyboard, or storage device to the
hardware platform through the USB ports. You can connect a monitor through the
DVI-I interface. A monitor, USB mouse, and USB keyboard are necessary only for user
interaction with the controller or with other software. To use the restore DVD, you need a
‘USB DVD-ROM drive. You do not need a storage device for WinLC RTX operation except
when restoring your installation.
The hardware platform contains NVRAM. You can use this non-volatile RAM for retentive
data storage. WinAC RTX is pre-configured to store up to 128 Kbytes of retentive data in this
integrated, battery-buffered NVRAM of the hardware platform.
If the retentive data is greater than 128 Kbytes, you must select "File storage" for WinAC
data storage. The hardware platform uses a CompactFlash card for file storage. In order to
save retentive data in a power loss situation, protect your system with an Uninterruptible
Power Supply (UPS).
Typically, you use the Enhanced Write Filter (EWF) to protect the C:\ drive of the
CompactFlash card; however, you must take care to manage the EWF if you use the
C:\ drive for any file storage. Typically, you leave the EWF disabled for the D:\ drive.
File storage on the D:\ drive thus requires no special handling.
Refer to the WinAC RTX documentation for information on configuring WinAC data storage.
In addition to this documentation, you can find technical specifications and other information
in the SIMATIC Embedded Bundles product documentation. Refer to the accompanying
WinAC RTX documentation for a complete description of WinAC RTX and how to use it for
PC-based Automation solutions. The
Introduction (Page 5) of this documentation lists other
manual
s that may be useful.
