Overview
1.1 Product description
SIMATIC IPC427E
10 Operating Instructions, 09/2017, A5E37454814-AB
1.1.1
Applications
The device provides industrial PC systems for high-performance and space-saving
applications in particular in the field of machine, systems and switchgear cabinet
engineering:
● Measuring and controlling process and machine data, for example, automated washing
systems, assembling machines and packaging machines
● Operating and visualization tasks with separate monitors or displays, for example,
information terminals and large-scale displays in automotive production
● Data logging and processing, for example, system data logging and distributed process
control
1.1.2
Features
Basic data
Installation
• Installation on a DIN rail
• Wall mounting
• Vertical mounting
Processor
• Intel® Celeron® Processor G3902E (2M Cache, 1.6 GHz)
• Intel® Core™ i3-6102E Processor (3M Cache, 1.9 GHz)
• Intel® Core™ i5-6442EQ Processor (6M Cache, up to 2.7 GHz)
• Intel® Xeon® Processor E3-1505L v5 (8M Cache, up to 2.8 GHz)
Main memory
Memory modules without ECC:
• 4 GB DDR4-SDRAM SODIMM
• 8 GB DDR4-SDRAM SODIMM
• 16 GB DDR4-SDRAM SODIMM
Memory module with ECC (not combinable with i5 CPU):
• 8 GB DDR4-SDRAM SODIMM
• 16 GB DDR4-SDRAM SODIMM
Free slots for expansion
cards
Up to 2 × PCIe cards (optional), depending on enclosure version;
max. 175 mm long
Graphics
• Intel® HD Graphics 510 / 530 / P530 (depending on CPU type)
• 2 x DisplayPort, maximum resolution 4096 x 2304 pixels
• Graphics memory is claimed in main memory (dynamic UMA)
Power supply
24 V DC (-20%/+20%) max. 4 A
Conditions of use
Operation without fan
