Expanding and assigning parameters to the device
6.1 Installing and removing the memory module
SIMATIC IPC427E
64 Operating Instructions, 09/2017, A5E37454814-AB
The motherboard is equipped with one slot for an SO-DIMM DDR4 memory module. You
can use it to expand the memory capacity of the device to a maximum of 16 GB.
modules recommended by Siemens AG.
● The device is disconnected from the power supply.
● The device is open (see sections "Opening the device (Page 61)" and "Opening the
device containing expansion cards (Page 63)").
Note
Observe the directives on handling electrostatic
-sensitive components in ESD guideline
98).
Push down the module clips towards the
outside.
The memory module tilts forward.
Remove the memory module from the
slot.
