Siemens SIMATIC IPC427E User Manual

Technical specifications
8.5 Technical specifications
SIMATIC IPC427E
Operating Instructions, 09/2017, A5E37454814-AB
105
8.5
Technical specifications
8.5.1
General technical specifications
General technical specifications
Article numbers
See order documents
Dimensions (base device)
262 × 133 × 55.5 (W × H × D in mm).
Weight
Base device:
Device with 2x expansion
Approx. 2.2 kg
Approx. 2.7 kg
Supply voltage (DC)
1
24 V DC
1
(-20%/+20%)
Short-term voltage interruption in
accordance with Namur
Min. 15 ms (at 20.4 V)
Max. 10 events/h; recovery time min. 1 s
Max. power consumption 64.8 W (at 24 V)
Degree of protection
IP 20 to IEC 60529
Protection class
Protection class I to IEC 61140
Safety specifications EN 60950-1; UL 60950-1; CAN/CSA-C22.2 No. 60950-1;
UL 508; CAN/CSA-C22.2 No. 142
Noise emission
<40dB (A) to DIN 45635-1
Quality assurance
In accordance with ISO 9001
1
The device should only be connected to a 24 V
DC power supply which meets the re-
qu
irements of safe extra low voltage (SELV) according to IEC/EN/DIN EN/UL 60950-1.
The power supply must meet the requirement NEC Class 2 or LPS according to the
IEC/EN/DINEN/UL 60950-1 (see section "Connecting the power supply (Page 41)").
