Technical specifications
8.5 Technical specifications
SIMATIC IPC427E
106 Operating Instructions, 09/2017, A5E37454814-AB
Electromagnetic compatibility
EN 61000-6-3, EN 61000-6-4, CISPR22 class B; FCC class A
Immunity with regard to conduct-
ed interference on the supply lines
± 2 kV according to IEC 61000-4-4; burst
± 1 kV according to IEC 61000-4-5; symmetrical surge
± 2 kV according to IEC 61000-4-5; asymmetrical surge
Noise immunity on signal lines ± 1 kV to IEC 61000-4-4; Burst; Length < 3 m
± 2 kV in accordance with IEC 61000-4-4; Burst; length > 3 m
± 2 kV in accordance with IEC 61000-4-5; Surge; length > 30 m
Immunity to electrostatic dis-
± 6 kV contact discharge in accordance with IEC 61000-4-2
± 8 kV air discharge in accordance with IEC 61000-4-2
Immunity to RF interference 10 V/m 80–2000 MHz, 80% AM according to IEC 61000-4-3
3 V/m 2–2.7 GHz, 80% AM according to IEC 61000-4-3
10 V 10 KHz–80 MHz, 80% AM according to IEC 61000-4-6
Immunity to magnetic fields
100 A/m, 50/60 Hz according to IEC 61000-4-8
Processor
• Intel® Celeron® Processor G3902E (2 MB cache, 1.6 GHz)
• Intel® Core™ i3-6102E Processor (3 MB cache, 1.9 GHz)
• Intel® Core™ i5-6442EQ Processor (6 MB cache, up to
2.7 GHz)
• Intel® Xeon® Processor E3-1505L v5 (8 MB cache, up to
2.8 GHz)
Main memory Memory modules without ECC:
• 4 GB DDR4-SDRAM SODIMM
• 8 GB DDR4-SDRAM SODIMM
• 16 GB DDR4-SDRAM SODIMM
Memory module with ECC (not combinable with i5 CPU):
• 8 GB DDR4-SDRAM SODIMM
• 16 GB DDR4 SDRAM SODIMM
1
Expansion card slots up to 2 x PCIe cards can be used
Max. length of PCIe cards: 175 mm
max. permitted power losses: 8 W per PCIe card, 12 W in total
1
For devices with retentivity
