Extended device functions
5.1 Monitoring Functions
SIMATIC IPC427E
50 Operating Instructions, 09/2017, A5E37454814-AB
Temperature monitoring/display
The temperature is recorded by means of three temperature sensors. The sensors monitor
the processor temperature and the temperature in the area of the RAM module and the
motherboard at the display port sockets.
The following fault reaction is triggered if one of the three temperature values exceeds the
set thermal threshold:
Alarm window of the DiagBase or DiagMonitor software alerts the user.
The temperature error is saved until the temperatures have fallen below the thresholds and it
is reset by one of the following measures:
● Acknowledgment of the error message by the user with DiagBase or DiagMonitor
software
● Restart of the device
