Device maintenance and repair
7.3 Installing and removing hardware
SIMATIC IPC427E
78 Operating Instructions, 09/2017, A5E37454814-AB
7.3.2
Changing storage media
7.3.2.1
Replacing a HDD/SSD
This procedure applies to the replacement of the built-in HDD or SSD.
Requirement
The device is disconnected from the power supply.
The device is removed.
1 T10 screwdriver
Procedure
Note
Observe the guidelines for handling electrostatic
-sensitive components in section "ESD
guideline
(Page 98)".
Removal
1.
Remove the wall mounting bracket or the
vertical mounting
bracket, if any, and
then the indicated screws.
Push the cover in the direction indicated
and lift it off.
2.
Remove the marked screws.
These screws secure the HDD/SSD.
