Device maintenance and repair
7.3 Installing and removing hardware
SIMATIC IPC427E
Operating Instructions, 09/2017, A5E37454814-AB
79
3.
Remove the HDD/SSD from the encl
o-
sure.
4.
Loosen the HDD/SSD on the side from
the base plate as shown.
The HDD/SSD is retained on the base
plate b
y means of the studs shown. An
additional insulating film is inserted into
the base plate for HDD operation.
Installation
1.
Place the HDD/SSD onto the base plate.
Observe the recess position shown when
installing an SDD. The SSD interfaces
should be located opposite the recess.
2.
Insert the new HDD/SSD into the encl
o-
sure.
Take care that the nameplate
is on top.
Slide the HDD/SSD into the enclosure
until you can see the mounting holes.
